TLC Plates POLYGRAM® ALOX N / UV254, 5 x 20 cm, 50 Piece(s)

TLC Plates POLYGRAM® ALOX N / UV254, 5 x 20 cm, 50 Piece(s)

SKU N740.1
€ 112,88
In stock
1
Save this product for later
TLC Plates POLYGRAM® ALOX N / UV254, 5 x 20 cm, 50 Piece(s)
Product Details
HS code: 38229000
EAN: 8721028178152
Brand: Macherey-Nagel
Material: polyester with aluminium oxide, with fluorescence indicator.

Aluminium oxide (ALOX)

  • Specific surface: approx. 200 m2/g
  • Indicator: manganese-activated zinc silicate
  • Mean pore width: 60 Å
  • Inert organic binder

Tip: We recommend to activate aluminium oxide layers before use by heating at 120 °C for10 minutes.


Further attractive products to complete your chromatography laboratory can be found on our Chromatography page!



TLC Plates POLYGRAM® ALOX N / UV254

Technical Information
Plate format 5 x 20 cm
Layer thickness 0.2 mm
Material polyester
Modification Aluminium oxide layer
Fluorescent indicator yes
Phase ALOX N
Recommended application(s) Terpenes, Alkaloids, Steroids, Aliphatic and aromatic compounds

Further attractive products to complete your chromatography laboratory can be found on our Chromatography page!


Thin Layer Chromatography (TLC)

Although the principle of thin-layer chromatography is more than a century old, it did not make its breakthrough as an analytical method until about 50 years ago.
Thanks to the development of new sorbents and supports, as well as increasing instrumentation and automation, TLC has become a versatile separation method. It is used both in qualitative analysis and in quantitative analysis.
Applications range from simple manual separation processes in classic TLC to automated processes in HPTLC (high performance thin layer chromatography).

Advantages of thin layer chromatography:

  • Higher sample throughput in less time
  • Suitable for screening tests
  • Pilot process for HPLC
  • The ready-to-use TLC layer functions as a data storage device for separation results
  • The separated substances can be used later for further analysis (e.g. IR, MS)
  • By switching the mobile and the stationary phases, the separation process can be optimised quickly and cost-efficient
