Home/Store/Laboratory supplies/Transport, storage and laboratory equipment/Gas handling
Gas pressure reducer two-stage, brass, 0.1 - 3 bar, hydrogen 1 Piece

Gas pressure reducer two-stage, brass, 0.1 - 3 bar, hydrogen 1 Piece

SKU C292.1
€ 916,78
In stock
1
Save this product for later
Gas pressure reducer two-stage, brass, 0.1 - 3 bar, hydrogen 1 Piece
Product Details
HS code: 84811099
Material: Brass
Brand: AirLiquide
Material: brass, chrome-plated.

For all pure and ultra-pure gas mixtures, apart from acetylene and corrosive gases. For applications requiring a constant initial pressure.



Gas pressure regulator two-stage Back pressure up to 3 bar

Technical Information
Gas type Hydrogen
Back pressure 0,1-3 bar
Readability 0.1 bar
Bottle connection W 21.8 x 1/14″ left
Upstream pressure, max. 200 bar
Inlet connection bottle connection according to DIN 477
Outlet connection clamping ring screw connection for 6 mm pipe
Total leakage rate 3 x 10-7 mbar l/s
Operating temperature -20 to +50 °C
L x W x H 180 x 98 x 135 mm
Weight 1,6 kg
Show More
