Flat flange reaction vessel cylindrical, graduated (1) Round bottom, DN 60, 65 mm, Height, 85 mm, 1 Piece

Flat flange reaction vessel cylindrical, graduated (1) Round bottom, DN 60, 65 mm, Height, 85 mm, 1 Piece

SKU 212K.1
€ 188,64
In stock
1
Save this product for later
Flat flange reaction vessel cylindrical, graduated (1) Round bottom, DN 60, 65 mm, Height, 85 mm, 1 Piece
Product Details
HS code: 70172000
Material: DURAN®-glass
EAN: 8721028094971
Brand: Lenz
Material: DURAN® glass.

Reaction vessel, cylindrical, graduated with groove in the flat flange. The flat flange reaction vessel is closed with a lid which is available separately. Both parts are held together by a clamping ring. A sealing ring, or the use of grinding grease, prevents the grinding surfaces from jamming. Suitable silicone and FEP sealing rings are available separately. The flat flange vessel can be combined with other components (e.g. coolers, stirrer shafts and dropping funnels) by means of various standard ground joints in the lid.Areas of application: preparatory work, such as general reactions, distillation, evaporation and drying, in which solid or viscous substances are produced.

  • Excellent chemical resistance
  • High temperature resistance
  • Suitable for use under vacuum
  • Flat flange with groove: a sealing ring can be inserted into the groove to seal the vessel tightly


Flat flange reaction vessel cylindrical, graduated (1) Round bottom

Delivery incl. flat flange reaction vessel. Delivery without flat flange lid, sealing ring and clamping ring; please order separately.
Technical Information
Version DN 60
Nominal volume 100 ml
Ø ext. 65 mm
Ø internal 60 mm
Height 85 mm
Show More
