Stirrer EUROSTAR 100 P4 control for 100 liters of liquid, 174 W

Stirrer EUROSTAR 100 P4 control for 100 liters of liquid, 174 W

SKU 25004384
€ 3 755,37
In stock
1
Save this product for later
Stirrer EUROSTAR 100 P4 control for 100 liters of liquid, 174 W
Product Details
Max. stirring volume: 100 L
Viscosity max.: 100000 mPas
Engine power: 174 W

The extremely powerful laboratory stirrer EUROSTAR 100 control P4 with a

removable wireless controller and a digital TFT display is especially

suitable for highly viscous applications and provides a torque of up to

320 Ncm. It automatically adjusts the speed through microprocessor

controlled technology within the speed range of 0/10 - 300 rpm. The

stirrer comes equipped with a RS 232 and a USB interface to control and

document all parameters. Furthermore, an integrated torque trend display

is provided for the measurement of viscosity changes and its electronic

safety circuit ensures automatic cut-off in an anti-stall or overload

conditions. Continuous comparison of shaft speed to desired speed is

maintained and variations are adjusted automatically. This guarantees a

constant speed even with changes in viscosities of the sample.

  • Reverse function
  • Multilingual TFT display
  • Programmable functions
  • Integrated temperature measurement
  • Interval operation
  • Timer function
Stirring quantity max. per stirring position (H2O) 100 l
Motor rating input 174 W
Motor rating output 142 W
Motor principle Brushless DC
Speed display TFT
Speed range 10 - 300 rpm
Reversible direction of rotation yes
Intermittent operation yes
Viscosity max. 100000 mPas
Output max. at stirring shaft 100 W
Permissible ON time 100 %
Torque max. at stirring shaft 320 Ncm
Speed adjustment stepless
Setting accuracy speed ±1 rpm
Deviation of speed measurement n < 300rpm ±3 rpm
Stirring element fastening chuck
Connection for ext. temperature sensor PT1000
Temperature display yes
Chuck range diameter 0.5 - 10 mm
Fastening on stand extension arm
Extension arm diameter 16 mm
Extension arm length 220 mm
Torque display yes
Nominal torque 3.20 Nm
Torque measurement trend
Deviation of torque measurement I ±30 Ncm
Timer yes
Timer display TFT
Time setting range 1 - 6000 min
Temperature measuring range -10 - +350 °C
Temperature measurement resolution 0.1 K
Accuracy of temperature measurement ±0.5 + tolerance PT1000 (DIN EN 60751 Class A) K
Limit deviation temperature sensor ≤ ± (0.15 + 0.002xITI) K
Housing material alu-cast coating / thermoplastic polymer
Communication distance (depend onbuilding) max. 150 m
Dimensions (W x H x D) 86 x 352 x 230 mm
Weight 5.2 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity 80 %
Protection class according to DIN EN 60529 IP 40
RS 232 interface yes
USB interface yes
Voltage 230 V
Frequency 50/60 Hz
Power input 150 W
  • Adjustable safety circuit
  • Locked function
  • Infinitely adjustable speed
  • Push-through agitator shafts
  • Overload protection
  • Short-term overload operation
  • Quiet operation
  • Error code Display
  • H 67.60 temperature sensor and WH 11 WiCo holder included in delivery
