Stirrer EUROSTAR 20 high speed control for 20 liters of liquid, 176 W
SKU 25001314
€ 2 735,54
In stock
1
Save this product for later
Stirrer EUROSTAR 20 high speed control for 20 liters of liquid, 176 W
Product Details
Max. stirring volume: 20 L
Viscosity max.: 10000 mPas
Engine power: 176 W
High speed laboratory stirrer designed with a removable wireless
controller and a digital TFT display. It automatically adjusts the speed
through microprocessor controlled technology within the speed range of
0/150 - 6000 rpm. The stirrer comes equipped with a RS 232 and a USB
interface to control and document all parameters, and an update of the
current firmware. An integrated torque trend display is provided for the
measurement of viscosity changes. The included precision stirrer shaft
is 280 mm long and has a maximum immersion depth of 220 mm.
- Multilingual TFT display
- Programmable functions
- Integrated temperature measurement
- Interval operation
- Timer function
- Adjustable safety circuit
- Locked function
- Infinitely adjustable speed
- Push-through agitator shafts
- Overload protection
- Short-term overload operation
- Slim casing
- Quiet operation
- Error code display
- H 67.60 temperature sensor and WH 11 WiCo holder included in delivery
| Stirring quantity max. per stirring position (H2O) | 20 l |
| Motor rating input | 176 W |
| Motor rating output | 125 W |
| Motor principle | Brushless DC |
| Speed display | TFT |
| Speed range | 0/150 - 6000 rpm |
| Intermittent operation | yes |
| Viscosity max. | 10000 mPas |
| Output max. at stirring shaft | 125 W |
| Permissible ON time | 100 % |
| Torque max. at stirring shaft | 20 Ncm |
| Speed adjustment | stepless |
| Setting accuracy speed | ±1 rpm |
| Deviation of speed measurement n > 300rpm | ±1 % |
| Deviation of speed measurement n < 300rpm | ±3 rpm |
| Stirring element fastening | special output shaft |
| Connection for ext. temperature sensor | PT1000 |
| Temperature display | yes |
| Fastening on stand | extension arm |
| Extension arm diameter | 16 mm |
| Extension arm length | 220 mm |
| Torque display | yes |
| Nominal torque | 0.2 Nm |
| Torque measurement | trend |
| Deviation of torque measurement I | ±6 Ncm |
| Timer | yes |
| Timer display | TFT |
| Time setting range | 1 - 6000 min |
| Temperature measuring range | -10 - +350 °C |
| Temperature measurement resolution | 0.1 K |
| Accuracy of temperature measurement | ±0.5 + tolerance PT1000 (DIN EN 60751 Class A) K |
| Limit deviation temperature sensor | ≤ ± (0.15 + 0.002xITI) K |
| Housing material | alu-cast coating / thermoplastic polymer |
| Communication distance (depend onbuilding) max. | 150 m |
| Dimensions (W x H x D) | 86 x 325 x 230 mm |
| Weight | 5.242 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 40 |
| RS 232 interface | yes |
| USB interface | yes |
| Voltage | 230 V |
| Frequency | 50/60 Hz |
| Power input | 176 W |
