Stirrer EUROSTAR 400 digital for 150 liters of liquid, 220 W
SKU 4214000
€ 3 289,26
In stock
1
Save this product for later
Stirrer EUROSTAR 400 digital for 150 liters of liquid, 220 W
Product Details
Max. stirring volume: 150 L
Viscosity max.: 100000 mPas
Engine power: 220 W
Powerful laboratory stirrer for high viscous applications and intensive
mixing for quantities up to 150 l (H2O). It automatically adjusts the
speed within the range of 0/6 – 2000 rpm (two speed ranges) through
microprocessor controlled technology. Integrated safety circuits ensure
automatic cut-off in an anti-stall or overload conditions. Continuous
comparison of shaft to desired speed is performed and variations are
adjusted automatically. This ensures constant speed even with changes in
viscosities of the sample.
- Digital speed display
- Infinitely adjustable speed
- Push-through agitator shafts
- Overload protection
- Short-term overload operation
- Slim casing
- Quiet operation
- Error code display
| Stirring quantity max. per stirring position (H2O) | 150 l |
| Motor rating input | 220 W |
| Motor rating output | 176 W |
| Motor principle | Brushless DC |
| Speed display | 7 segment LED |
| Speed range | 0/6 - 2000 rpm |
| Viscosity max. | 100000 mPas |
| Output max. at stirring shaft | 167 W |
| Permissible ON time | 100 % |
| Torque max. at stirring shaft | 400 Ncm |
| Torque I max. | 400 Ncm |
| Torque II max. | 80 Ncm |
| Speed range I (50 Hz) | 6 - 400 rpm |
| Speed range II (50 Hz) | 30 - 2000 rpm |
| Speed range I (60 Hz) | 6 - 400 rpm |
| Speed range II (60 Hz) | 30 - 2000 rpm |
| Speed adjustment | stepless |
| Setting accuracy speed | ±1 rpm |
| Deviation of speed measurement n > 300rpm | ±1 % |
| Deviation of speed measurement n < 300rpm | ±3 rpm |
| Stirring element fastening | chuck |
| Chuck range diameter | 3 - 16 mm |
| Hollow shaft, inner diameter | 10.3 mm |
| Hollow shaft (push-through - when stopped) | yes |
| Fastening on stand | extension arm |
| Extension arm diameter | 16 mm |
| Extension arm length | 160 mm |
| Speed control | electronic |
| Nominal torque | 4 Nm |
| Dimensions (W x H x D) | 114 x 325 x 245 mm |
| Weight | 8.4 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 42 |
| Voltage | 230 V |
| Frequency | 50/60 Hz |
| Power input | 226 W |
