Stirrer EUROSTAR 60 digital for 40 liters of liquid, 176 W
SKU 0004446000
€ 1 385,95
In stock
1
Save this product for later
Stirrer EUROSTAR 60 digital for 40 liters of liquid, 176 W
Product Details
Max. stirring volume: 40 L
Viscosity max.: 50000 mPas
Engine power: 176 W
Universally used strong laboratory stirrer for quantities up to 40 l (H2O). It automatically adjusts the speed through microprocessor controlled technology within the speed range of 0/30 - 2000 rpm. Safety circuits installed ensures automatic cut-off in an anti-stall or overload conditions. Continuous comparison of shaft speed to desired speed is maintained and variations are adjusted automatically. This guarantees a constant speed even with changes in viscosities of the sample.
- Digital speed display
- Infinitely adjustable speed
- Push-through agitator shafts
- Overload protection
- Short-term overload operation
- Slim casing
- Quiet operation
- Error code display
| Stirring quantity max. per stirring position (H2O) | 40 l |
| Motor rating input | 176 W |
| Motor rating output | 126 W |
| Motor principle | Brushless DC |
| Speed display | 7 segment LED |
| Speed range | 0/30 - 2000 rpm |
| Viscosity max. | 50000 mPas |
| Output max. at stirring shaft | 126 W |
| Permissible ON time | 100 % |
| Torque max. at stirring shaft | 60 Ncm |
| Speed adjustment | stepless |
| Setting accuracy speed | ±1 rpm |
| Deviation of speed measurement n > 300rpm | ±1 % |
| Deviation of speed measurement n < 300rpm | ±3 rpm |
| Stirring element fastening | chuck |
| Chuck range diameter | 0.5 - 10 mm |
| Hollow shaft, inner diameter | 11 mm |
| Hollow shaft (push-through - when stopped) | yes |
| Fastening on stand | extension arm |
| Extension arm diameter | 16 mm |
| Extension arm length | 220 mm |
| Speed control | electronic |
| Nominal torque | 0.6 Nm |
| Housing material | alu-cast coating / thermoplastic polymer |
| Dimensions (W x H x D) | 86 x 248 x 208 mm |
| Weight | 3.9 kg |
| Permissible ambient temperature | 5 - 40 °C |
| Permissible relative humidity | 80 % |
| Protection class according to DIN EN 60529 | IP 42 |
| Voltage | 230 V |
| Frequency | 50/60 Hz |
| Power input | 176 W |
