Stirrer MINISTAR 40 control for 25 liters of liquid, 60W

Stirrer MINISTAR 40 control for 25 liters of liquid, 60W

SKU 0025001989
€ 1 285,12
In stock
1
Save this product for later
Stirrer MINISTAR 40 control for 25 liters of liquid, 60W
Product Details
Max. stirring volume: 25 L
Viscosity max.: 30000 mPas
Engine power: 60 W

The new MINISTAR series by IKA: Developed using the latest cutting-edge technology, this high-tech overhead stirrer with its compact design is ideal for special applications.
Combining high performance with particular excellence, they require minimum space and come with a lifetime guarantee. See for yourself:



“The Universal” in the high-tech mini class, reaches up to 1000 RPM!

  • Hardened glass enclosed, fast response display for maximum visibility and chemical resistance
  • State-of-art vibration sensors detect deviations from permissible thresholds and automatically stop the process
  • Clear display for all essential information at a glance
  • Integrated timer / counter for the control of kinetic sensitive reactions and reminders
  • Viscosities up to 30,000 mPas and volume of up to 25 l
  • Continuously adjustable speed between 0/30 – 1,000 rpm
  • USB interface, e.g. for documenting parameters using labworldsoft® or installing firmware updates
  • Intuitive and simple handling; touch-sensitive surface for long service life
  • Temperature reading on display
  • Chemical resistant housing
  • Key lock function
  • Microprocessor-controlled speed governor for constant rotational speed, even with changes in viscosity
Stirring quantity max. per stirring position (H2O) 25 l
Motor rating input 60 W
Motor rating output 46 W
Motor principle Brushless DC
Speed display LCD
Speed range 0/30 - 1000 rpm
Viscosity max. 30000 mPas
Output max. at stirring shaft 42 W
Permissible ON time 100 %
Torque max. at stirring shaft 40 Ncm
Speed adjustment Turning knob
Setting accuracy speed ±1 rpm
Deviation of speed measurement n > 300rpm ±1 %
Deviation of speed measurement n < 300rpm ±3 rpm
Stirring element fastening chuck
Connection for ext. temperature sensor PT1000
Temperature display yes
Chuck range diameter 0.5 - 8.2 mm
Hollow shaft, inner diameter 8.5 mm
Hollow shaft (push-through - when stopped) yes
Fastening on stand extension arm
Extension arm diameter 13 mm
Extension arm length 160 mm
Torque display yes
Speed control electronic
Nominal torque 0.4 Nm
Torque measurement trend
Deviation of torque measurement I ±4 Ncm
Timer yes
Timer display LCD
Time setting range 0 - 6000 min
Temperature measuring range -10 - 350 °C
Temperature measurement resolution 0.1 K
Accuracy of temperature measurement ±0.5 + tolerance PT1000 (DIN EN 60751 Class A) K
Limit deviation temperature sensor ≤ ± (0.15 + 0.002xITI) K
Housing material alu-cast coating / thermoplastic polymer
Communication distance (depend onbuilding) max. 150 m
Dimensions (W x H x D) 70 x 193 x 154 mm
Weight 1.72 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity 80 %
Protection class according to DIN EN 60529 IP 54
USB interface yes
Voltage 100 - 240 V
Frequency 50/60 Hz
Power input 69 W
DC Voltage 24 V=
Current consumption 2900 mA
Show More
