Accessories Rupture disc protection II Rupture disc protection, 1 piece
SKU 3167.1
€ 1 415,98
In stock
1
Save this product for later
Accessories Rupture disc protection II Rupture disc protection, 1 piece
Product Details
HS code: 73072390
EAN: 8721028065858
Brand: Carl Roth
Accessories Bursting disc safety device II Bursting disc safety device
Bursting disc safety device II
With bursting disc protection device made of V4A stainless steel for autoclave head II.
Technical Information
| Type | Bursting disc safety device II |
OVERVIEWHigh-pressure laboratory autoclaves from ROTH
| Model 0 | Model I | Model II | Model IV | |||
| Max. working volume (ml) | 50 | 100 | 200 | 300 | 250 | 500 |
| Max. working pressure (bar) | 100 | 100 | 100 | 100 | 200 | 100 |
| Heating mantle | none | 10 S | 20 S | 30 S | 30 S | 50 S |
| Sampling possible | no | no | yes | yes | ||
| Stirrer connection possible | no | no | yes | yes | ||
| Temp. measurement in autoclave possible | no | no | yes | yes | ||
Attention
Due to the shape of the screw thread, cold setting of cylinder and head is possible when screwing these on. This usually leads to them sticking when opening and the thread breaking as a result.The conducted reaction necessitates coating the thread with a release agent such as PTFE spray (Art. No. K007.1).Warning: Do not use PTFE screw thread tape!
Advice for working with silver gaskets
When working with silver gaskets, it is essential to tighten the screw threads very tightly to achieve the necessary seat. We therefore recommend annealing the silver gaskets at +850 °C before use - the gaskets remain softer and more pliable, even when cool, and seal more efficiently.
