Transfer membrane ROTI®FluoroPVDF, 20 × 13 cm, 2 Piece(s)

Transfer membrane ROTI®FluoroPVDF, 20 × 13 cm, 2 Piece(s)

SKU 2831.1
€ 32,85
In stock
1
Save this product for later
Transfer membrane ROTI®FluoroPVDF, 20 × 13 cm, 2 Piece(s)
Product Details
HS code: 39209952
Material: PVDF
EAN: 8721028170248
Brand: Carl Roth
Material: polyvinylidene fluoride (PVDF).

PVDF membrane for protein analyses.

ROTI®PVDF is a hydrophobic, microporous polyvinylidene membrane, free from adjuvants and detergents. With this membrane, efficient transfers of proteins can be carried out over a wide molecular weight range.


Directions for use

The membrane shows superior protein binding parameters and stands out for its particularly low background. It may also be used very well after repeated stripping and harsh washing processes.
This mechanically rigid transfer membrane can be easily cut to the desired gel size and it remains flexible and tear-proof even when dry.
Briefly immerse the membrane membrane in 100 % methanol prior to transfer until no more white areas are visible. This transfer membrane is then compatible with every blotting system.
Due to production processes, the membrane shows two different sides - one smooth and one raw. For optimally distinct bands, please use the smooth side for protein binding.



Transfer membrane ROTI®FluoroPVDF
Suitable for

ROTI®Fluoro PVDF has been specially optimised for direct detection via fluorescence.
ROTI®Fluoro PVDF binds proteins adhesively via hydrophobic interactions. It enables very sensitive protein detection by keeping the background very low, resulting in a good signal-to-noise ratio with all standard detection systems. The mechanically rigid membrane is of high tensile strength and tear-proof, and does not crack or curl during handling. Therefore, signals remain clear and distinct, and are undisturbed by false-positive signals caused by membranes crinkles.
Briefly immerse ROTI®Fluoro PVDF membrane in 100 % methanol prior to transfer until no more white areas are visible. This transfer membrane is then compatible with every aqueous transfer system.

The membrane ROTI®Fluoro PVDF is only conditionally suitable for use with chemiluminescence detection. The membranes are specially coated for fluorescence applications and this coating can reduce the sensitivity of chemiluminescence. For chemiluminescent assays we recommend the use of ROTI®PVDF membranes.
Detection systems: fluorescence, radioactivity, colour

  • Western and Far Western Blotting
  • Immunoblotting
  • Dot blots
  • Small peptide analyses
  • Binding assays
  • N-terminal sequencing


Technical Information
Dimensions 20 × 13 cm
Version sheet
Pore size 0,2 µm
Bond hydrophobic
Binding capacity 300 µg/cm²
Immobilisation not necessary

Technical Parameters of ROTH-Transfer Membranes

Membrane Material Characteristics Thickness (μm) Binding capacity (μg/cm2) Pore size (μm) Immobilisation
Roti® Fluoro PVDF Polyvinyliden fluoride hydrophobic 125 ±25 300 0,2 not necessary
Roti® PVDF 0.2 Polyvinyliden fluoride hydrophobic 140 ±20 ≥125 0,2 not necessary
Roti® PVDF Polyvinyliden fluoride hydrophobic 125 ±25 ca. 200 0,45 not necessary
Immobilon P Polyvinyliden fluoride hydrophobic 120 ±25 150-300 0,45 not necessary
Roti® Nylon 0.2 Nylon 6,6 neutral/amphoteric 150 ±20 500 0,2/0,45 UV, baking
Roti® Nylon plus Nylon 6,6 hydrophilic, positively charged 160 ±20 500 0,45 not necessary, UV and baking possible
Roti® NC Nitrocellulose electrostatic, hydrophobic 150 ±50 125-200 0,2 UV, baking (max. 80 °C)
Roti® NC 0.45 Nitrocellulose electrostatic, hydrophobic 150 ±10 ≥125 0,45 UV, baking (max. 80 °C)
Amersham Protran® Nitrocellulose electrostatic, hydrophobic unknown 11-72 0,2/0,45 UV, baking (max. 80 °C)
Amersham Protran® supported Nitrocellulose electrostatic, hydrophobic unknown 86-110 0,2/0,45 UV, baking (max. 80 °C)

Size Comparison of Membrane Pores and Biomolecules

Biomolecules / Membrane Pores Size (kD)
genomic DNA (human) >11000000
E. coli approx. 1500000
0.45 μm approx. 5000
0.2 μm approx. 2000
DNA 3 kb approx. 1000
RNA 1 kb approx. 300
Antibodies (IgG) approx. 150
Proteins in the lab approx. 10–300
BSA (Albumin) 69

Application of ROTH-Transfer Membranes

Biomolecules Nylon plus Nylon 0.2 PVDF 0.2 PVDF Fluoro PVDF NC NC 0.45
DNA +++ + - - - + +
RNA + +++ - - - + +
Proteins - + +++ +++ +++ + +
Detection System
Colour +++ +++ +++ +++ +++ +++ +++
Radioactivity +++ +++ +++ +++ +++ +++ +++
Chemoluminescence +++ +++ +++ +++ - + +
Fluorescence +++ +++ - - +++ - -
+++: recommended +: suitable -: not
