Water jet pump, 1 piece

Water jet pump, 1 piece

SKU 7366.1

€ 61,69

In stock

Quantity:

1

Save this product for later

Water jet pump, 1 piece

Product Details

HS code: 84138100

Material: PP

EAN: 8721028082312

Brand: Brand GmbH & Co.

Material: PP.

For extraction of liquids and vapours as well as generating vacuum. With built-in non-return valve. Can be disassembled, making cleaning easy.

Connection for the tap:

Union nut R³/₄? or
Reducer R¹/₂? or
Hose connection (connector) with outer Ø 10-12 mm
Optional accessory (please order separately):
adapter from R³/₄? to M22 x 1 (perlator thread), with seal

Vacuum connection:

Connector with outer Ø 6-9 mm

Technical specifications:

Water consumption: approx. 220 l/h at a flow pressure of 3.5 bar
Delivery rate: approx. 450 l of air/h at a flow pressure of 3.5 bar
Abs. end vacuum at a water pressure of 3.5 bar:
approx. 16 mbar at +12 °C
approx. 24 mbar at +20 °C
Length of the water jet pump with R³/₄? connection: approx. 210 mm

Water jet pump

Technical Information

Version

Water jet pump
