HPTLC Plates ALUGRAM® Nano-SIL NH2 / UV254 - amino-modified, 20 x 20 cm, 25 Piece(s)
SKU 3767.1
€ 644,14
In stock
1
Save this product for later
HPTLC Plates ALUGRAM® Nano-SIL NH2 / UV254 - amino-modified, 20 x 20 cm, 25 Piece(s)
Product Details
HS code: 38229000
Material: Aluminium
EAN: 8721028182371
Brand: Macherey-Nagel
Material: aluminium with amino-modified nano silica gel 60, with fluorescence indicator.
Aminopropyl modification
Carbon content 3,5 %
- pH stability: 2-8
- Layer can be equally well wetted by pure water and organic solvents, respectively.
Order of polarity:
silica > DIOL > NH2 > CN > RP-2 > RP-18 W
Further attractive products to complete your chromatography laboratory can be found on our Chromatography page!
HPTLC Plates ALUGRAM® Nano-SIL NH2 / UV254 - amino-modified
Technical Information
| Plate format | 20 x 20 cm |
| Layer thickness | 0.15 mm |
| Material | aluminium |
| Modification | Silica gel with Amino (NH2) modification |
| Fluorescent indicator | yes |
| Separation principle | Normal phase (NP) |
| Phase | Nano-SIL NH2 |
| Particle size | 2-10 µm |
| Particle type | Fully porous particles (FPP) |
| Pore size | 60 Å |
| Pore volume | 0.75 ml/g |
| pH stability | 2,0-8,0 |
| Temperature stability | High |
| Recommended application(s) | Nucleotides, Pesticides, Phenols, Purine derivatives, Reversed phase (RP) and Normal phase (NP), Steroids, Sugars, Vitamins, Xanthines |
Further attractive products to complete your chromatography laboratory can be found on our Chromatography page!
Thin Layer Chromatography (TLC)
Although the principle of thin-layer chromatography is more than a century old, it did not make its breakthrough as an analytical method until about 50 years ago.
Thanks to the development of new sorbents and supports, as well as increasing instrumentation and automation, TLC has become a versatile separation method. It is used both in qualitative analysis and in quantitative analysis.
Applications range from simple manual separation processes in classic TLC to automated processes in HPTLC (high performance thin layer chromatography).
Advantages of thin layer chromatography:
- Higher sample throughput in less time
- Suitable for screening tests
- Pilot process for HPLC
- The ready-to-use TLC layer functions as a data storage device for separation results
- The separated substances can be used later for further analysis (e.g. IR, MS)
- By switching the mobile and the stationary phases, the separation process can be optimised quickly and cost-efficient
